The SUNPASS FEP Encapsulated Seal FO00010 is crafted with a seamless and uniform Teflon® FEP encapsulation that fully encases a core material of either silicone or Viton® elastomers. This synergistic blend of materials results in a seal that boasts exceptional chemical inertness and resistance to compression set, making it ideal for deployment in the most demanding sealing environments.
Encapsulated Seal VS Solid PTFE
Standard elastomeric seals, while versatile, may lack the necessary chemical resistance required for specific applications, leading to potential material degradation and seal failure. Conversely, solid PTFE seals, known for their excellent chemical inertness, often fall short in providing the necessary elasticity for reliable, long-term fluid sealing due to their rigid nature. To address these challenges, advanced sealing solutions are engineered by incorporating these materials into a variety of general and high-performance elastomers. This customization ensures compatibility with the vast majority of industrial applications and specialized environments, including those involving oil and other demanding fluids.
Service capabilities
Continuous Service temperature: -60℃ to +200℃
| SUNPASS CODE | TYPE | SIZE | |||
| FO00009 | DN500 | (DIA. 16MM) SECTION*486MM INNER DIA | |||
| FO00010 | DN500 | (14MM*14MM) SECTION*486MM INNER DIA | |||
| FO00011 | DN300 | (14MM*14MM) SECTION*294MM INNER DIA | |||
Many dimensions are availiable as well as special seals to suit specific manlids
Jednoducho, môžete nakupovať vo veľkoobchode FEP Encapsulated Seal priamo od výrobcov.
1. Exceptional Chemical Resistance: The material is highly resistant to a broad spectrum of chemicals, ensuring reliability in diverse applications.
2. Superior to Solid PTFE O-Rings: Offers enhanced performance compared to traditional solid PTFE O-Rings, providing a better solution for sealing challenges.
3. Broad Temperature Tolerance: Capable of withstanding a wide range of temperatures, making it suitable for both low and high-temperature environments.
4. Non-Stick Surface: Features a smooth, non-stick surface that resists adhesion of substances, facilitating easy cleaning and maintenance.
5. Low Friction Coefficient: Exhibits a low coefficient of friction, reducing wear and improving the efficiency of moving parts.
6. Sanitary: Designed for easy cleaning and meeting high standards of hygiene, ideal for use in food processing and pharmaceutical industries.
7. Customizable Sizes: Available in unlimited sizes to accommodate specific requirements and applications.
8. Minimal Compression Set: Demonstrates a low compression set, maintaining its shape and sealing properties over time.
